Diamond/CBN Grinding Wheel


A Diamond grinding wheel and CBN grinding wheel are a fairly new product. Theny have numerous shapes like flat disks, cups, cylinders, cones, and wheels with profiles cut into their periphery etc. Diamond as also CBN grinding wheels are usually classified by shape, their grit size, the concentration and bond. Clients can acording to the hardness of the cutting material to select the grit size of the abrasive for the diamond grinding wheels and CBN grinding wheel.
